EUROLITE SB-1200B Power Distributor
1
de
4
Cargando...
€527,95
Precio por unidad
/
No disponible
Incl. IVA • B2B sin IVA
Envío gratis
Descripción
Descripción
Practical 63 A distributor in 483 mm housing (19")
- Specially designed for larger distribution needs
- With earthing screw
- (19") 48.3 cm rack installation 3 U
Scope of delivery
- 1 x device
- 1 x user manual
| Power supply: | 380-400V AC, 50Hz |
| Power connection: | Fixed power supply cord with CEE 63A 5-pin |
| Cable construction: | 5 x 16 mm² H07RN-F |
| Cable length: | 1 m |
| Power output: | 2 x CEE 32A 5-pol (F) recessed mounting fused 2 x CEE 16A 5-pol (F) recessed mounting fused |
| Protection: | 1 x fault-current circuit breaker (FI) Typ B 63A/0.03A 4-pol 2 x circuit breaker C 16A 3-pol 2 x circuit breaker C 32A 3-pol |
| Phase status display: | 3 |
| Housing design: | (19") 48.3 cm rack installation 3 U |
| Dimensions: | Width: 48.3 cm Depth: 31 cm Height: 13.35 cm |
| Weight: | 8.15 kg |
