Roland Boutique TB-03
Descripción
Descripción
- Remake realista del icónico sintetizador TB-303 Bass Line
- Control manual de parámetros, incluyendo cutoff, resonance, envelope mod, decay y accent
- Programable a través de los modos de escritura classic Pitch, Time y Step
- Salidas CV/Gate para controlar equipos analógicos vintage y sintetizadores modulares
- Alimentado por batería (4 x AA) o USB
- Altavoz mini integrado alimentado
Roland TB-03
TB-03 es un remake digital del icónico sintetizador TB-303 Bass Line. Mismo sonido e interfaz de usuario que en el original TB-303. Nuevas características que no se encuentran en el original TB-303 incluyen un display LED de 4 dígitos, overdrive y efectos de delay, MIDI, control de tempo fino y control de patrones. Se puede programar a través de los clásicos modos de escritura Pitch, Time y Step.
Especificaciones
Especificaciones
-
Weight (kg)
Más especificaciones
Más especificaciones
- SPECIFICATIONS Roland TB-03
- User Memory
- Patterns: 96 (4 groups (I, II, III, IV) x 3 sections (A, B, C) x 8 patterns)
Tracks: 7 - Waveform
- (SAW, SQUARE)
- Controllers
- BVOLUME knob
TUNING knob
CUT OFF FREQ knob
RESONANCE knob
ENV MOD knob
DECAY knob
ACCENT knob
OVERDRIVE knob
DELAY TIME knob
DELAY FEEDBACK knob
WAVE FORM switch
TRACK PATT. GROUP selector
MODE selector
TEMPO button
VALUE knob
PATTERN CLEAR button
RUN/STOP button
PITCH MODE button
FUNCTION button
Keyboard buttons (C, C#, D, D#, E, F, F#, G, G#, A, A#, B, C)
TIME MODE button
TRANSPOSE UP/DOWN buttons
ACCENT button
SLIDE button
BACK button
TAP button - Effects
- OVERDRIVE (Overdrive/Distortion)
DELAY (Tape Echo/Digital Delay/Reverb) - Indicators
- 7 segments, 4 characters (LED)
PITCH MODE LED
NORMAL MODE LED
TIME MODE LED - Connectors
- TRIGGER IN jack: Mono miniature phone type
CV OUTPUT jack: Mono miniature phone type
GATE OUTPUT jack: Mono miniature phone type
PHONES jack: Stereo miniature phone type
OUTPUT jack: Stereo miniature phone type
MIX IN jack: Stereo miniature phone type
MIDI (IN, OUT) connectors
USB port: Micro-B type (Audio, MIDI) - Power Supply
- Rechargeable Ni-MH battery (AA, HR6) x 4
Alkaline battery (AA, LR6) x 4
USB bus power - Current Draw
- 500 mA (USB bus power)
- Expected battery life under continuous use
- Rechargeable Ni-MH battery: Approx. 5 hours
* This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use. - ACCESSORIES
- Owner's Manual
DK-01 Owner's Manual
Leaflet "USING THE UNIT SAFELY"
Alkaline battery (AA, LR6) x 4 - SIZE AND WEIGHT
- Width
- 308 mm
12-1/8 inches - Depth
- 130 mm
5-1/8 inches - Height
- 52 mm
2-1/16 inches - Weight
- 940 g
2 lbs 2 oz
